Product Information - Auto Quantitative Feeder

Inquire Now Add to Inquiry Cart

Click for a larger picture.

Auto Quantitative Feeder

Product Description

Product Name:

Auto Quantitative Feeder

Model:

QF-1~QF-5

Detail Specifications

▶▶ Features  :
  • This is a high-accurate powder feeder which is employed in a manufacturing process especially requiring mini volume continuous automatic feeding
  • This weighing feeder provides a continuous automatic feeding of few pulsation in connection with the controller which has numerous achievements
  • A good selection of a screw unit allows a mini volume feeding of fine powder from 0.2~2 l/h
  • Flow accuracy 0.5~1% of full scale
▶▶ Specification  :
MODEL SCREWDLA
mm		 POWER
HP		 FEED
RATE
L/H		 DIMENSIONS
L W H
QF-1 25 1/8 8-80 1100 800 1200
QF-2 50 1/4-1 65-650 1100 800 1200
QF-3 75 1/4-1 200-2000 1100 800 1200
QF-4 100 1/2-1 550-5500 1270 900 1300
QF-5 150 1/2-1 1650-16500 1270 900 1300
▶▶ Flow-Sheet  :
